CALL FOR PRICE
Got a remote vessel or stand-alone worksite? Choose compact non-contact radar (CNCR)! Small but mighty, CNCR-300 series sensors come in ranges of 49’ and 98’ to provide inventory control and level measurements to industries and applications where a lack of access to power is a frequent obstacle.
Non-contact radar is the gold standard for small bins, tanks, and silos. Pair with ToughSonic® ultrasonic sensors for a comprehensive smart inventory management system.
Wire-Free: CNCR-300 sensors are Lithium battery-powered for streamlined installation
Liquids or Solids: A leading choice for any industry that requires bulk material measurements
Remote-Vessel Friendly: Ideal choice for hard-to-access structures or bins without power
Variety of Mounting Options: 3" and 4" mounting flanges
The CNCR’s Advanced Features
80 GHz Technology: Narrow 8° beam is unaffected by dust, foam, or condensation
Incredible Accuracy: Precision within ±0.08 in. (2 mm)
Bluetooth Configurable: Convenient sensor setup using Bluetooth on a cell phone
Durable Design: PVDF housings are heat, chemical, abrasion, weather, and flame resistant
NO Deadband/Dead Zone: Measure material up to the radar face without sacrificing accuracy
Big Radar Benefits
Cloud-Based Measurements: Wirelessly transmits data to the Cloud; no need for on-site Internet
Non-Contact: CNCRs do not contact the material being measured, making them an ideal choice for sanitary or hygienic applications
Impenetrable & Protected: Enclosures are IP 66/68 rated against dust and water ingress
Safer Employees: Eliminate treacherous ladder climbing and liability, and lessen labor costs
Low Cost of Ownership: Radars require little to no maintenance after installation
View Inventory Remotely: With BinCloud® inventory management software, view data anytime, anywhere via phone, tablet, or PC
s
Common Applications for CNCR-300 Series Radars
Agrichemicals: Meter staple farming chemicals like pesticides, fertilizers, and fuels
Mining Operations: Uninterrupted accuracy in dusty and noisy clinker silos and rock crushers; remote monitoring of water tanks and process liquids
Grain Storage: Monitor tall and narrow bins, or get single-point measurements of grain piles or flat storage warehouses
Industrial Bulk Containers (IBCs): Measure levels in containers, drums, and totes; top-mount a sensor or measure through a plastic wall
Civil Engineering: Utilize for road salt loadouts, pavement coating tanks, and bulk cement or aggregate materials
| Maximum Range | 98 ft. (30 m) for liquids; 48 ft. (14 m) for solids |
| Optimum Range | 0 inches to 65.62 ft (20 m) |
| Deadband | N/A |
| Temperature | -40° to +176°F (-40° to +80°C) |
| Humidity | 0 to 100% operating |
| Protection | IP 66, IP 68 |
| Voltage | Battery power (Lithium) |
| Voltage Output | Long-Range (LoRa) |
| Accuracy | ±0.78 inches (2 mm) |
| Frequency | 80 GHz radar wave |
| Approvals | Ordinary locations |
Mechanical
| Housing | Plastic |
| Mounting |
4" adapter flange |
| Total Weight | 52.96 oz (1.50 kg) |
*Specifications are subject to change without notice.
