ToughSonic® TS-200 ultrasonic level sensors deliver non-contact, highly accurate liquid level measurement in chemical tanks, diesel fuel storage, and industrial liquid applications. Designed for durability, these compact and rugged sensors withstand exposure to harsh chemicals, acids, and bases. They are ideal for demanding paper processing, food production, and industrial storage applications.
Chemical-Resistant PVDF Housing: Ensures long-term performance in corrosive environments.
Non-Contact Ultrasonic Technology: Accurate level measurement without sensor contact with the liquid.
Wide Application Use: Suitable for closed or open tanks, chemical processing, and diesel fuel storage.
Extreme Durability: Rated IP68, NEMA-4X, and NEMA-6P for reliable indoor and outdoor use.
Advanced Configuration: Easily adjustable with SensorView™ software for setup, testing, and cloning sensors.
Short Nose & Deadband: Measures closer to the full tank for improved accuracy.
Versatile Mounting Options: Features 1.5-inch and 2.0-inch BSP bottom threads and 1.0-inch NPT top threads.
TS-200: Versatile in Tough Environments
Flexible Installation Options: Top and bottom mounting threads
Ingress Protection: IP68 (submersible), NEMA-4X, NEMA-6P
Output Options: Five outputs plus serial data
Temperature Compensation: Ensures accuracy in varying conditions
PC Configurable: Adjust sensor settings easily
Measures Up to Challenging Applications
Chemical Tank Level Monitoring: Safe for use in chemical environments compatible with PVDF.
Aggressive Materials & Fuel Storage Tanks: Reliable level measurement in hostile applications.
Industrial & Factory Environments: Designed for use in the harshest conditions.
Agriculture: Liquid level monitoring in irrigation systems, ag chemicals, livestock monitoring.
Open-Air Liquid Level Monitoring: Measures tank levels up to 14, 20, or 35 feet.
| Maximum Range | 35 feet (10.7 meters) |
| Optimum Range | 12 inches to 25 feet (30.5 cm to 7.6 meters) |
| Deadband | 0-12 in (0-30.5cm) |
| Temperature | -40° to 158°F (-40° to 70°C) |
| Humidity | 0 to 100% operating |
| Protection | NEMA-4X, NEMA 6P, IP68 |
| Transducer | Chemically isolated piezoelectric |
| Compensation | Temperature compensated (selectable in SensorView™) |
| Resolution | Serial data: 0.0034 in.
(0.086 mm) Analog steps: 4099 (0-10 VDC), 3279 (4-20 mA) |
| Repeatability | Nominal 0.2% of range @ constant temp. Affected by target, distance, environment |
| Update Rate | 20 Hz (50 ms), SensorView adjustable; affected by SensorView filter selections |
Outputs
| Voltage Output | 0-10, 0-5 VDC or SensorView customized 10 mA maximum output current |
| Current Loops (x2) | Two 4-20 mA current loops: Current sourcing and current sinking Max loop resistance, 450 ohms each SensorView customized Both share calibration parameters |
| Switches (x2) | Two switches, SensorView customized 150 mA max @ 40 VDC max SensorView selected as sinking (NPN) or sourcing (PNP) Adjustable setpoint, polarity, hysteresis, ON and OFF timing |
| Serial Data Interface | Modbus & streaming protocols 9600-115200 baud (configurable) 8 data bits, 1 stop, no parity RS-485 permits multi-sensor networks Part number determines interface |
Mechanical
| Housing | Injection moulded, chemically resistant Polyvinylidene fluoride (PVDF) Also known as Kynar, a registered tradename of Arkema Inc. |
| Mounting |
Top mount: 1-inch NPT (options available) Bottom: 2 in. straight, fits NPT or BSP Bottom nut UA-NUT20-PV (order separately) |
| Cable | Potted into sensor, pigtail termination 6.5 feet (2 meters), PUR jacketed Custom lengths available Standard models: 9-wire shielded + drain Serial data-only models: 4-wire + drain |
| Total Weight | 24.7 oz. (0.70 kg) Weight includes 6.5 ft (2 meter) cable |
*Specifications are subject to change without notice.
ToughSonic®-200.35 Level Sensor Data Sheet
ToughSonic®-200 Manual
